Jet Water Hose

产品概述 | Product Overview

高压冲水管主要用于耙吸船拖头冲水系统、绞刀辅助冲洗系统及其他需要高压供水的疏浚设备单元,用于冲散沉积物、辅助松动介质并改善吸排效率。该类产品通常要求具备较高的耐压能力、良好的柔性和稳定的连接可靠性,以适应设备运动、海水环境和频繁启停带来的工况变化。

Jet water hose is typically used on draghead flushing systems, cutter support flushing systems and other dredging equipment that requires high-pressure water delivery. The hose is designed to combine pressure retention, flexibility and connection reliability so that it can perform under equipment movement, marine exposure and repeated start-stop flushing duty.

技术参数 | Technical Parameters

参数Parameter 规格Specification
型号Model GS-DG29-JW
内径InsideDiameter 100mm-450mm
工作压力WorkingPressure 2.5MPa
试验压力Test Pressure 3.75MPa
标准长度Standard Length 10m-11.8m
输送介质Typical Medium 淡水 / 海水 Fresh Water / Seawater
连接形式End Connection 法兰 / 快速接头 Flange / Quick Coupling
外覆层Cover 耐候耐海水外胶 Weather and Seawater Resistant Cover
